Hustler | Super Z HyperDrive

The Super Z® HyperDrive® features Hustler’s exclusive HyperDrive transmission system – the largest, most durable drive system in the industry. And, it’s backed by a 3,000 drive system warranty.

 Highlights
  • 60”, 66” or 72” VX4® deck
  • Heavy-duty fabricated frame
  • Exclusive SmoothTrak™ steering
  • Patented automatic park brake
  • HyperDrive® Hydro System – mow in tough conditions without losing performance
  • HyperDrive 5-year/3000 hour pump and motor warranty
  • Six-way adjustable premium Grammer suspension seat with smooth ride isolator
  • Unmatched innovative transmission system
  • 16 mph top speed
  • Powerful engine options
  • 13” front and 26” drive tires
  • Product_Hero_Image_Super_Z_HyperDrive.png50
  • Product_Hero_Image_Super_Z_HyperDrive.png50

Engine

Zero-Turn Configuration 60″ Vanguard Big Block 72″ Vanguard Big Block 72″ Vanguard Big Block EFI
Manufacturer Vanguard Vanguard Vanguard
HP (Per SAE J 1995.) 36HP 36HP 37HP
Displacement 933cc 933cc 933cc
Cooling Air Cooled Air Cooled Air Cooled
Air Cleaner Heavy-Duty Canister Heavy-Duty Canister Heavy-Duty Canister
Engine Warranty 5 Year – Vanguard Only 5 Year – Vanguard Only 5 Year – Vanguard Only

Drive System

Zero-Turn Configuration 60″ Vanguard Big Block 72″ Vanguard Big Block 72″ Vanguard Big Block EFI
Type Dual Hydrostatic Dual Hydrostatic Dual Hydrostatic
Pumps Danfoss DDC-20 Danfoss DDC-20 Danfoss DDC-20
Wheel Motors Parker TG280 Parker TG280 Parker TG280
Hydraulic Lines Stainless Steel Parker Seal Loc Technology Stainless Steel Parker Seal Loc Technology Stainless Steel Parker Seal Loc Technology
Hydraulic Cooling Oil Cooler w/ 9″ Fan Oil Cooler w/ 9″ Fan Oil Cooler w/ 9″ Fan
Reservoir Capacity 3 gal. 3 gal. 3 gal.
Transmission n/a n/a n/a
Speed 16 mph 16 mph 16 mph
Parking Brakes Patented Automatic Patented Automatic Patented Automatic

Decks

Zero-Turn Configuration 60″ Vanguard Big Block 72″ Vanguard Big Block 72″ Vanguard Big Block EFI
Cutting Width 60″ 72″ 72″
Cutting Heights 1″-5.5″ 1″-5.5″ 1″-5.5″
Deck Lift Foot Operated Foot Operated Foot Operated
Depth 5.5″ 5.5″ 5.5″
Blades 3 3 3
Blade Length 3 – 20.5″ x 3.0″ x .25″ 3 – 24.5″ x 3.0″ x .25″ 3 – 24.5″ x 3.0″ x .25″
Blade Tip Speed 18,630 fpm 18,530 fpm 18,530 fpm
Spindles Ductile Cast Iron w/ Steel Shafts and Sealed Ball Bearings Ductile Cast Iron w/ Steel Shafts and Sealed Ball Bearings Ductile Cast Iron w/ Steel Shafts and Sealed Ball Bearings
Deck Belts 1 1 1
Drive Electric PTO Clutch Electric PTO Clutch Electric PTO Clutch
Construction 7ga. Welded Steel 7ga. Welded Steel 7ga. Welded Steel
Spindle Mounts Reinforced 7ga. spindle mount disc Reinforced 7ga. spindle mount disc Reinforced 7ga. spindle mount disc
Impact/Trim Areas 11ga. formed channel w/ rolled edge 11ga. formed channel w/ rolled edge 11ga. formed channel w/ rolled edge

Construction

Zero-Turn Configuration 60″ Vanguard Big Block 72″ Vanguard Big Block 72″ Vanguard Big Block EFI
Frame 1.5″ x 3.0″ x .187″ Steel 1.5″ x 3.0″ x .187″ Steel 1.5″ x 3.0″ x .187″ Steel
Deck Carrier Frame n/a n/a n/a
Engine/Transmission Frame n/a n/a n/a
Engine Plate n/a n/a n/a
Front Axle n/a n/a n/a
Front Caster Wheels Mounted tapered greasable bearings Mounted tapered greasable bearings Mounted tapered greasable bearings
Front Caster Forks Fabricated 1/2″ Steel Fabricated 1/2″ Steel Fabricated 1/2″ Steel
Operator Platform n/a n/a n/a

General

Zero-Turn Configuration 60″ Vanguard Big Block 72″ Vanguard Big Block 72″ Vanguard Big Block EFI
Seat Grammer Suspension Seat w/ Isolator Grammer Suspension Seat w/ Isolator Grammer Suspension Seat w/ Isolator
Fuel Capacity 12 gal. 12 gal. 12 gal.
Cup Holder Yes Yes Yes
Front Tire 13 x 6.5 – 6 13 x 6.5 – 6 13 x 6.5 – 6
Drive Tire 26 x 12 – 12 26 x 12 – 12 26 x 12 – 12

Productivity

Zero-Turn Configuration 60″ Vanguard Big Block 72″ Vanguard Big Block 72″ Vanguard Big Block EFI
Acres per Hour 7.76 9.31 9.31

Dimensions

Zero-Turn Configuration 60″ Vanguard Big Block 72″ Vanguard Big Block 72″ Vanguard Big Block EFI
Weight 1525 lbs. 1585 lbs. 1585 lbs.
Height n/a n/a n/a
Height w/ ROPS Up 71.5″ 71.5″ 71.5″
Height w/ ROPS Folded 54″ 54″ 54″
Length 84.5″ 86.7″ 86.7″
Width n/a n/a n/a
Width w/ Chute Up 66″ 78″ 78″
Tire Width 57″ 60″ 60″

Dimensions w/ Catcher

Zero-Turn Configuration 60″ Vanguard Big Block 72″ Vanguard Big Block 72″ Vanguard Big Block EFI
Catcher Type 3-bag 3-bag 3-bag
Powered/Non-powered Powered Powered Powered
Catcher Capacity 12 bushel 12 bushel 12 bushel
Mower Length w/ Catcher 114.9″ 119.2″ 119.2″
Mower Width w/ Catcher 70.9″ 82.9″ 82.9″
Catcher Type BAC-VAC BAC-VAC BAC-VAC
Powered/Non-powered Powered Powered Powered
Catcher Capacity 10 bushel 10 bushel 10 bushel
Mower Length w/ Catcher 108.4″ 112.7″ 112.7″
Mower Width w/ Catcher 70.9″ 82.9″ 82.9″





 Warranty

The Super Z® HyperDrive® has the best warranty in its class in the ind

Hustler® mowers are built to the highest of standards, but our unmatched warranties provide extra peace of mind. See your local Hustler® dealer for complete details.
